LAN / Firewall NUSO Setup

Modified on Tue, 7 Oct at 10:30 AM

Since VOIP traffic flows through your router, its important to make sure your router is configured to allow traffic to and from NUSO's switch. Please reference the document below.




Logo1

METASWITCH VOICE / LAN CHANGES



Allow inbound / outbound traffic to the following IPs:



SBC IPs:

4.28.93.167

8.40.32.227

64.20.190.27

38.91.65.157

IP Blocks:

4.28.93.128/25

4.79.132.208/28

4.53.160.128/28

4.53.160.64/27

38.104.160.16/28

38.91.65.128/25

8.40.32.0/24

64.20.190.0/26

206.166.213.0/24



Recommended Firewall Settings:

Disable SIP ALG / SIP Transformations

Enable Consistent NAT

Increase or disable UDP timeout. 10 minutes or greater. (600 seconds)
